FAQ:
1. Are there any tutorials and software installation guides available?
Yes, please refer to this curriculum link: 35-ips-screen.rtfd.io
2. Does the 3.5’’ touchscreen support Raspberry Pi OS (Trixie)?
Yes. The 3.5’’ touchscreen is fully supported on the Trixie system.
3. Can this screen work on Ubuntu, Kali Linux, or RetroPie?
Yes, but only with specific OS versions. If you install an unsupported version, the screen may not work after installing the driver.
Supported systems:
Raspberry Pi OS
Trixie Desktop (64-bit) (released: 2025-12-04), Bookworm Desktop (64-bit) (released: 2025-11-24, 2025-05-13, 2025-05-06)
After installing the driver on Bookworm, run startx to enter the desktop environment.
Ubuntu: ubuntu-24.04.4-preinstalled-desktop-arm64+raspi (Raspberry Pi 4 only);
Kali Linux: kali-linux-2025.3-raspberry-pi-arm64
RetroPie: Retropie Download page (Raspberry Pi 4 only)
4. Can I use the screen without installing drivers?
No. This screen uses an SPI interface and requires a dedicated driver to function.
5. Why does my screen stay black or white after powering on?
Make sure the correct driver is installed. Ensure your operating system is compatible. Check that the screen is properly connected to the GPIO pins.
6. What if I get git not found or network errors during installation?
Make sure your Raspberry Pi is connected to the internet. If Git is not installed, run: sudo apt update, sudo apt install git
Then retry the installation.
7. Why is the screen orientation incorrect?
You can fix the screen and touch orientation by running:
cd LCD-show/ (adjust the path depending on your OS), sudo ./rotate.sh 90
Replace 90 with 0, 180, or 270 as needed.
8. Can I use the 3.5’’ IPS screen together with an HDMI monitor?
No. After installing the 3.5’’ IPS screen driver, it is recommended to disconnect the HDMI monitor.
If the HDMI monitor remains connected, it may show a black screen or no display output.
9. Why does the fan keep spinning?
Can it be controlled by software?
The fan header provides constant 5V power and does not support software control. The fan will always spin when connected.
10. What is the operating temperature range?
The supported operating temperature is -20°C to 60°C. Avoid exceeding this range to prevent damage or reduced lifespan.
